914CE1-6G Honeywell Limit Switch
Non-returnable
₹1.00
Product Details
Product Details:
| Product | Description |
|---|---|
| Brand | Honeywell |
| Model no. | 914CE1-6G |
| Description | compact enclosed limit switch |
| Switching options | SPDT, snap action contacts (1NC/1NO) |
| Sealing | IP66, IP67, IP68 (depending upon model) NEMA 1, 2, 3, 3R, 4, 6, 6P, 12 (boot seal), 13 |
| Operating temperature (914CE) | 0 °C to 105 °C [32 °F to 221 °F] |
| Mechanical life | 10 million |
| Thermal current | 1 A |
| Rated insulation voltage (Ui) | 250 V |
| Rated impulse withstand voltage (Uimp) | 1.5 kV |
| Short circuit protection device (SCPD) | Quick blow fuse suitable for rated current of switch |
| Pollution degree | 3 |
| Min. actuation speed | 0.003 m/s |
| Max. actuation speed | 0.1 m/s |
| Max. actuation frequency | ac – 200 Hz; dc – 20 Hz |
| Shock | 50 g – IEC 60068-2-27 |
| Vibration | 10 g – IEC 60068-2-6 |
| Approvals | UL, CSA, CE |
